Heavy Plate Rolling Machine for Nuclear Power

China National Nuclear Power Equipment Co., LTD

Introduction: The company has A class industrial boiler manufacturing qualification, BRI class pressure vessel design and manufacturing qualification, 1000 Mwe nuclear power plant nuclear pressure equipment, nuclear chemical equipment manufacturing qualification, QTZ800 tower crane manufacturing qualification. Is specialized in industrial boiler, pressure vessel, nuclear equipment, lifting transportation equipment, wind power tower tube manufacturing professional company. The company has a strong product development and design ability, product design has been widely adopted computer-aided design (CAD) technology. Strictly and conscientiously implement the "quality first, reputation first" policy, the establishment of a perfect quality assurance system, in 1999, obtained the ISO9001 quality system certification certificate. The enterprise technology center was recognized as the "provincial technology center" by the Gansu Provincial government in 2003.

china national nuclear power equipment co., ltd

Order EZHONG products:

EZW11XY-8000T*3000 heavy plate rolling machine

EZW11XY-8000T*3000 Heavy Plate Rolling Machine

EZ（W11XY-8000T * 3000 Heavy plate rolling machine)

Main parameter table

specification
no.	Item	Unit	DATA
1	specifications	mm	XWIIS-200/360
2	Equipment rated down capacity	Tons	6000
3	Maximum coil width	mm	3000
4	The upper roller diameter	mm	1460
5	Lower roller diameter	mm	1225
6	The lower roller center distance is adjustable range	mm	1300-2450
7	Minimum drum diameter at full load	mm	3000
8	Plate coil temperature	C	-20
9	Plate yield limit	MPa	450
10	The maximum thickness of the plate	mm	200
11	The maximum thickness of overseas Chinese circle	mm	160
12	Prebend the remaining straight edge		2-2.5(Plate thickness）
13	The upper roller drives torque	KN.m	4250（0.610rpm)）
14	Lower roller drives torque	KN.m	152(0.728rpm)
15	Horizontal movement speed	Mm/min	--300
16	The upper roller presses down the speed	Mm/min	carrying idler -200
17	Up roll up speed	Mm/min	-200
18	The coil speed	Mm/min	-2800
19	Maximum working pressure of the hydraulic system Main cylinder diameter	MPa	25
20	Main cylinder diameter	mm	θ1260
21	Total installed power	KW	```550
